How To Choose The Best CNC Rotary Table?

How To Choose The Best CNC Rotary Table?

Rotary Table fixture

CNC Rotary Table is a precision work positioning device used in CNC machining centers to precisely position the component in desired angle to do multi-face operation in a single setup. Rotary tables can be interpolated as 4th axis with machines X,Y and Z axes to enable machining of profiles such a cam machining, blade machining, helical grooves etc. which is out of reach with a standard 3 axes machining center.

Based on the application one can use only the Rotary Table with some work holding fixture or will have to use some accessories like Dead Center or Revolving Center Tailstocks, Face Plate Tailstocks, Manual or Power Chucks etc.

There are some basic points which needs to be checked for correct sizing of Rotary Table.

Rotary Table selection guidelines

Rotary Table Selection based on Component Size
Check for the swing required on the component
Check  for Center Height of the Table
For Multi spindle Table check for the center distance between the spindles
In vertical condition if the length of the component is more than 100 mm it is recommended to use the tail stock support
Larger component can be used provided load and clamping torque is within capacity of the Rotary table. For larger swing use height Block.

Rotary Table Selection based on Clamping Torque

Check for the machining forces required to do the operation.
Check for the distance from the center where operation is to be carried out.
Calculate torque applied during machining ( Torque = Force x Distance)
Machining torque should be with in Clamp torque capacity of the Table
Check for the type of clamping required (Hydraulic or Pneumatic )

Rotary Table Selection based on Component Weight

Check the dead weight of the component and fixture.
The dead weight of component & fixture should be within the capacity of Load capacity of the Rotary Table.
With tail stock support Load capacity of the Rotary Table in vertical condition will become same as horizontal load capacity.

Rotary Table Selection based on Indexing Accuracy

Check for the accuracy requirement on the component.
If accuracy specified in mm, check for the diameter at which the accuracy is required.
Convert Indexing Accuracy of the Rotary Table specified in arc sec to mm at the diameter where the operation is to be carried out
(A = Tan Ө x R),
Ө = Indexing Accuracy (Ex: +/- 15” (30”sec))
R = Radius at which the operation to be carried out
A = Accuracy in μ
NOTE: Higher accuracy of +/- 5” can be achieved by using additional high resolution encoder mounted on the table axis.

Rotary Table Selection based on Machine Capacity

Check the Machine Strokes and ensure once Rotary Table is mounted on the Machine Bed, component falls in the machining area.
Also check for the Tool change position. While tool changing the tool should not foul with Rotary table.
Total weight of the Rotary table including the work holding should be with the capacity of the machine load capacity.

Rotary Table Selection based on fouling with machine guard

Check for fouling of Rotary table Sheet Guard with Machine guard after mounting on Machine bed locating on the center tenon slot.
If there is fouling we can use Rear Motor mounting Table, provided there is sufficient space between Machine table and Machine sheet guard when table is in extreme right hand side.

Rotary Table Selection based on controller feasibility

Check if Machine Controller is capable of taking 4th Axis Rotary Table and 5th Axis Rotary Table for single axis table and 4th and 5th axis for two axis tables.
We can also suggest stand-alone controller if the machine is not capable of handling 4th axis, provided  component does not need continuous interpolation with machine axes for performing the operation
In some cases controllers are capable for 4 regular axes and 5th axis can only do indexing.
We would be happy to assist you to provide correct selection of Direct Drive Rotary Table and its accessories. For more details please feel free to write to us at marketing@ucamind.com
